Binder KBF P 240 - Technical Data

KBF P + KBF LQC + KBWF (E6) 11/2016 page 168/189
25.4 Technical Data
Chamber size
240
720
Exterior dimensions
Width, net
mm / inch
925 / 36.42
1250 / 49.21
Height, gross (incl. castors)
mm / inch
1460 / 57.48
1925 / 75.79
Depth, net
mm / inch
800 / 31.50
890 / 35.04
Depth, gross (including door handle, I-triangle, connection
and 30 mm for cable)
mm / inch 880 / 34.65 970 / 38.19
Wall clearance rear (minimum) (spacers)
mm / inch
100 / 3.94
100 / 3.94
Wall clearance side (minimum)
mm / inch
160 / 6.29
160 / 6.29
Doors
Quantity of doors
1
2
Quantity of inner glass doors
1
2
Interior dimensions
Width
mm / inch
650 / 25.60
973 / 38.31
Height
mm / inch
785 / 30.91
1250 / 49.21
Depth
mm / inch
485 / 19.09
576 / 22.68
Interior volume
l / cu.ft.
247 / 8.7
700 / 24.7
Steam space volume
l / cu.ft.
348 / 12.3
918 / 32.4
Racks
Quantity of racks (regular)
2
3
Quantity of racks (max.)
7
12
Quantity of light cassettes
2
3
Maximum load per rack
kg / lbs.
30 / 66
45 / 99
Maximum permitted total load
kg / lbs.
100 / 220
150 / 331
Weight
Weight (empty)
kg / lbs.
214 / 472
374 / 825
Temperature data (without humidity)
Temperature range without light cassettes
°C / °F
0 to +70 / 32 to 158
Temperature range with light cassettes, with illumination
°C / °F
+10 to +60 / 50 to 140
Max. heat compensation at 40 °C / 104 °F, with illumina-
tion
W 400 1000
Climatic data (with humidity) for KBF P / KBF LQC
Temperature range without light cassettes °C / °F
+10 to +70 /
50 to 158
+10 to +70 /
50 to 158
Temperature range with light cassettes, with illumination °C / °F
+10 to +60 /
50 to 140
+20 to +60 /
68 to 140
Temperature fluctuation
with illumination
at 25 °C / 77 °F and 60% r.H.
± K
0.2
0.2
at 40 °C / 104 °F and 75% r.H.
± K
0.2
0.2
Temperature uniformity
(variation) with illumination
at 25 °C / 77 °F and 60% r.H.
± K
0.6
1.2
at 40 °C / 104 °F and 75% r.H.
± K
0.6
1.2
Humidity range without light cassettes
% r.H.
10 to 80
10 to 80
Humidity range with light cassettes, with illumination
% r.H.
10 to 75
10 to 75
Humidity fluctuation with
illumination
at 25 °C / 77 °F and 60% r.H.
± % r.H.
≤ 1.5
≤ 2.0
at 40 °C / 104 °F and 75% r.H.
± % r.H.
≤ 2.0
≤ 2.0
Recovery time after doors
were open for 30 sec.
at 25 °C / 77 °F and 60% r.H.
minutes
4
4
at 40 °C / 104 °F and 75% r.H.
minutes
6
5
