KBF P + KBF LQC + KBWF (E6) 11/2016 page 95/189
Pressing the Reset alarm icon mutes the buzzer for all active alarms. The icon then disappears.
• Acknowledging while the alarm condition persists: Only the buzzer turns off. The visual alarm indication
remains on the controller display. The alarm remains in the list of active alarms.
When the alarm condition has ended, the visual alarm indication is automatically cleared. The alarm is
then no longer in the list of active alarms.
• Acknowledging after the alarm condition has ended: The buzzer and the visual alarm indication are
reset together. The alarm is then no longer in the list of active alarms.
• The zero-voltage relay alarm output resets together with the alarm.
12.4 Tolerance range settings
In this menu you can set the deviation between the actual value and setpoint which that shall cause a
tolerance range alarm.
This function only activates after the set-point has been reached once.
Path: Main menu > Settings > Various
Submenu “Various”.
Select the field “Range alarm delay”.
Entry menu “Range alarm delay”.
Enter the time in minutes, after which the range alarm
shall be triggered and press the Confirm icon.
Setting range: 15 min to 120 min.
Submenu “Various”.
Select the field ”Temperature range”.
“Temperature range” entry menu.
Enter the desired value for the temperature range
and press the Confirm icon.
Setting range: 2 °C to 20 °C
