KBF P + KBF LQC + KBWF (E6) 11/2016 page 151/189
21.9 External freshwater and wastewater cans (option)
If no suitable in-house water connection is avai
lable, you
can manually supply water by filling the optional external
freshwater can. There is an additional external water can
for the waste water. Volume: 20 liters / 0.71 cu.ft.
The cans are placed in holding devices. You can affix
them directly at the rear of the chamber
next to the chamber.
Figure 36: Rear chamber view with installed external
water cans (option)
21.9.1 Mounting the freshwater can
(1) Fixing (if required)
Hang the can with its holding device on its 4 carriers. You can install it either at the left or the right
side.
Cable connection (15)
Freshwater hose connection (16)
Figure 37: Freshwater can (option)
