KBF P + KBF LQC + KBWF (E6) 11/2016 page 92/189
Condition
Information
icon
Text information
Start after
condition occurred
KBF P / KBF LQC: VIS light turned on (oper-
ation line “Light VIS” activated)
Light VIS
immediately
KBF P / KBF LQC: UVA light turned on (op-
eration line “Light UVA” activated)
Light UVA
immediately
KBF LQC: Light integration activated (opera-
tion line “LQC On” activated)
LQC On
immediately
KBWF: Light level 1 (40% illumination) turned
on (operation line “Light level 1” activated)
Light level 1
immediately
KBWF: Light level 2 (60 % illumination)
turned on (operation line “Light level 2” acti-
vated)
Light level 2
immediately
Notifications are not shown in the event list.
12.1.2 Messages when reaching a dose target value – KBF LQC
When the VIS target dose is reached the corresponding line in Normal Display is highlighted in green, and
the message VIS dose reached is displayed in the event list.
When the UVA target dose is reached the corresponding line in Normal Display is highlighted in green,
and the message UVA dose reached is displayed in the event list.
As soon as the second target dose is reached as well, in addition the alarm message VIS and UVA dos-
es reached is displayed, and a buzzer sounds. The alarm can be acknowledged on the controller. The
alarm message is displayed in the event list.
