142 Operating Instructions ACTIVE 06/07
Digital Inputs Function
224 - Logic module 3
Signal from output of logic module 3, according to
parameterized
Operation Mode Logic 3 205.
225 - Logic module 3 inverted Inverted signal from output of logic module 3.
226 - Logic module 4
Signal from output of logic module 4, according to
parameterized
Operation Mode Logic 4 503.
227 - Logic module 4 inverted Inverted signal from output of logic module 4.
270 to 276
Operation modes 70 to 76 of the digital inputs
inverted (LOW active).
282 - Arrived at desired Position
Reference orientation 469 of axle positioning
reached.
320 - EM-S1IND
2)
Signal at digital input 1 of an EM extension mod-
ule or remote control via communication interface
321 - EM-S2IND
2)
Signal at digital input 2 of an EM extension mod-
ule or remote control via communication interface
322 - EM-S3IND
2)
Signal at digital input 3 of an EM extension mod-
ule or remote control via communication interface
520 - EM-S1IND inverted Operation mode 320 inverted.
521 - EM-S2IND inverted Operation mode 321 inverted.
522 - EM-S3IND inverted Operation mode 322 inverted.
525 - S1IND (Hardware)
1)
Digital input S1IND (X210A.3).
526 - S2IND (Hardware)
1)
Digital input S2IND (X210A.4).
527 - S3IND (Hardware)
1)
Digital input S3IND (X210A.5).
528 - S4IND (Hardware)
1)
Digital input S4IND (X210A.6).
529 - S5IND (Hardware)
1)
Digital input S5IND (X210A.7).
530 - S6IND (Hardware)
1)
Digital input S6IND (X210B.1).
531 - MFI1D (Hardware)
1)
Multifunction input MFI1 (X210B.6) in
Operation Mode 452 = 3 - digital input.
532 - EM-S1IND (Hardware)
1)
Digital input 1 of an EM extension module.
533 - EM-S2IND (Hardware)
1)
Digital input 2 of an EM extension module.
534 - EM-S3IND (Hardware)
1)
Digital input 3 of an EM extension module.
537 to 545
Operation modes 525 to 533 of the digital inputs
inverted (LOW active).
700 - RxPDO1 Boolean1
3)
Signal if an optional expansion module EM with
system bus is used.
701 - RxPDO1 Boolean2
3)
Signal if an optional expansion module EM with
system bus is used.
702 - RxPDO1 Boolean3
3)
Signal if an optional expansion module EM with
system bus is used.
703 - RxPDO1 Boolean4
3)
Signal if an optional expansion module EM with
system bus is used.
710 to 713
3)
Operation modes 700 to 703 for RxPDO2 with an
expansion module EM.
720 to 723
3)
Operation modes 700 to 703 for RxPDO3 with an
expansion module EM.
730 - Sysbus Emergency
3)
Signal if an optional expansion module EM with
system bus is used.
1)
The digital signal is independent of the setting of parameter Local/Remote 412.
2)
Refer to operating instructions of extension modules EM-IO
3)
Refer to operating instructions "System bus EM-SYS extension module“
