206 Operating Instructions ACTIVE 06/07
Error Environment
No. Description Unit Display range Chapter
330 DC link voltage V 0.0 ... U
dmax
19.2
331 output voltage V 0.0 ... U
FIN
19.2
332 Stator Frequency Hz 0.00 ... 999.99 19.2
333 Encoder 1 Frequency Hz 0.00 ... 999.99 19.2
335 Phase Current Ia A 0.0 ... I
max
19.2
336 Phase Current Ib A 0.0 ... I
max
19.2
337 Phase Current Ic A 0.0 ... I
max
19.2
338 R.m.s Current A 0.0 ... I
max
19.2
339 Isd / Reactive Current A 0.0 ... I
max
19.2
340 Isq / Active Current A 0.0 ... I
max
19.2
341 Rotor Magnetizing Current A 0.0 ... I
max
19.2
342 Torque Nm
± 9999.9
19.2
343 Analog Input MFI1A %
± 100.00
19.2
346 Analog Output MFO1A V 0.0 ... 24.0 19.2
349 Repetition Frequency Output Hz 0.00 ... 999.99 19.2
350 Status of Digital Inputs - 00 ... 255 20.2
351 Status of Digital Outputs - 00 ... 255 20.2
352 Time since Release
h:m:s.ms
00000:00:00.000 19.2
353 Heat Sink Temperature deg.C 0 ... T
kmax
19.2
354 Inside Temperature deg.C 0 ... T
imax
19.2
355 Controller Status - C0000 ... CFFFF 20.3
356 Warning Status - A0000 ... AFFFF 20.4
357 Int Value 1 -
± 32768
19.2
358 Int Value 2 -
± 32768
19.2
359 Long Value 1 -
± 2147483647
19.2
360 Long Value 2 -
± 2147483647
19.2
361 Checksum - OK / NOK 19.2
Error List
362 No. of Errors - 0 ... 32767 19.1
363 No. of self acknowledged Errors - 0 ... 32767 19.1
Positioning
470 Rotations U
0.000 ... 1
⋅10
6
11.6
Digital Outputs
537 Actual Warning Mask - AXXXXXXXX 14.3.7
Self-configuration
797 SETUP Status - OK / NOK 7.5
