21.2 Parameter Menu (PARA)
Inverter Data
No. Description Unit Setting range Chapter
0 Serial Number - Characters 8.1
1 Optional Modules - Characters 8.2
12 Inverter Software Version - Characters 8.3
27 Set Password - 0 ... 999 8.4
28 Control Level - 1 ... 3 8.5
29 User Name - 32 characters 8.6
30 Configuration - Selection 8.7
33 Language - Selection 8.8
34 Program(ming) - 0 ... 9999 8.9
37 Start Positioning of Axle - Selection 11.6.2
Fan
39 Switch-On Temperature deg.C 0 ... 60 17.2
Digital Inputs
62 Frequency Motorpoti Up - Selection 14.4.9
63 Frequency Motorpot. Down - Selection 14.4.9
66 Fixed Frequency Change-Over 1 - Selection 14.4.8
67 Fixed Frequency Change-Over 2 - Selection 14.4.8
68 Start Clockwise - Selection 14.4.1
69 Start Anticlockwise - Selection 14.4.1
70 Data set change-over 1 - Selection 14.4.7
71 Data set change-over 2 - Selection 14.4.7
72 Percent Motorpoti Up - Selection 14.4.9
73 Percent Motorpoti Down - Selection 14.4.9
75 Fixed percentage value change-over 1 - Selection 14.4.8
76 Fixed percentage value change-over 2 - Selection 14.4.8
83 Timer 1 - Selection 14.4.4
84 Timer 2 - Selection 14.4.4
87 Start 3-wire-control - Selection 14.4.2
103 Error Acknowledgment - Selection 14.4.3
164 n-/M-Control Change-Over - Selection 14.4.6
Logic Modules
198 Operation mode Logic 1 - Selection 14.5.3
199 Input 1 Logic 1 - Selection 14.5.3
200 Input 2 Logic 1 - Selection 14.5.3
201 Operation mode Logic 2 - Selection 14.5.3
202 Input 1 Logic 2 - Selection 14.5.3
203 Input 2 Logic 2 - Selection 14.5.3
Digital Inputs
204 Therm. Contact - Selection 14.4.5
Logic Modules
205 Operation mode Logic 3 - Selection 14.5.3
206 Input 1 Logic 3 - Selection 14.5.3
207 Input 2 Logic 3 - Selection 14.5.3
Actual value memory
237 Reset Memory - Selection 18.3
