Controlled commissioning
No. Description Unit Setting range Chapter
369 Motor Type - Selection 7.2.3
Rated Motor Parameters
370 Rated Voltage V
0.17
⋅U
FIN
... 2⋅U
FIN
9.1
371 Rated Current A
0.01
⋅I
FIN
... 10⋅o ⋅ I
FIN
9.1
372 Rated Speed U/min 96 ... 60000 9.1
373 No. of Pole Pairs - 1 ... 24 9.1
374 Rated Cosinus Phi - 0.01 ... 1.00 9.1
375 Rated Frequency Hz 10.00 ... 1000.00 9.1
376 Rated Mech. Power kW
0.1
⋅P
FIN
... 10⋅P
FIN
9.1
Further motor parameters
377 Stator Resistance mOhm 0 ... 65535 9.2
378 Leakage Coeff. % 1.0 ... 20.0 9.2
System data
389 Factor Actual Value System - -100.000 ... 100.000 10.1
397 Nominal Volumetric Flow m3/h 1 ... 99999 10.2
398 Nominal Pressure kPa 0.1 ... 999.9 10.2
Pulse Width Modulation
400 Switching frequency - Selection 17.1
401 Min. Switching Frequency - Selection 17.1
Error/warning behavior
405 Warning Limit Short Term Ixt % 6 ... 100 12.1
406 Warning Limit Long Term Ixt % 6 ... 100 12.1
407 Warning Limit Heat Sink Temp. deg.C -25 ... 0 12.2
408 Warning Limit Inside Temp. deg.C -25 ... 0 12.2
409 Controller-Status Message - Selection 12.3
Bus controller
412 Local/Remote - Selection 17.3
Error/warning behavior
415 IDC Compensation Limit V 0.0 ... 1.5 12.4
417 Frequency Switch-Off Limit Hz 0.00 ... 999.99 12.5
Frequency Limits
418 Minimum Frequency Hz 0.00 ... 999.99 13.1
419 Maximum Frequency Hz 0.00 ... 999.99 13.1
Frequency ramps
420 Acceleration (Clockwise) Hz/s 0.00 ... 9999.99 13.7
421 Deceleration (Clockwise) Hz/s 0.01 ... 9999.99 13.7
422 Acceleration Anticlockwise Hz/s -0.01 ... 9999.99 13.7
423 Deceleration Anticlockwise Hz/s -0.01 ... 9999.99 13.7
424 Emergency Stop Clockwise Hz/s 0.01 ... 9999.99 13.7
425 Emergency Stop Anticlockwise Hz/s 0.01 ... 9999.99 13.7
426 Maximum Leading Hz 0.01 ... 999.99 13.7
430 Ramp Rise Time Clockwise ms 0 ... 65000 13.7
431 Ramp Fall Time Clockwise ms 0 ... 65000 13.7
432 Ramp Rise Time Anticlockwise ms 0 ... 65000 13.7
433 Ramp Rise Time Anticlockwise ms 0 ... 65000 13.7
