Operating Instructions ACTIVE06/07 209
06/07 Operating Instructions ACTIVE 209
Technology Controller
No. Description Unit Setting range Chapter
440 Operation mode - Selection 16.3
441 Fixed Frequency Hz -999.99 ... 999.99 16.3
442 max. P-Component Hz 0.01 ... 999.99 16.3
443 Hysteresis % 0.01 ... 100.00 16.3
444 Amplification - -15.00 ... 15.00 16.3
445 Integral Time ms 0 ... 32767 16.3
446 Ind. Volume Flow Control Factor - 0.10 ... 2.00 16.3
Block Frequencies
447 1st Blocking Frequency Hz 0.00 ... 999.99 13.9
448 2nd Blocking Frequency Hz 0.00 ... 999.99 13.9
449 Frequency Hysteresis Hz 0.00 ... 100.00 13.9
Multifunctional input 1
450 Tolerance Band % 0.00 ... 25.00 14.1.1.3
451 Filter Time Constant ms Selection 14.1.1.4
452 Operation mode - Selection 14.1
453 Error/Warning Behavior - Selection 14.1.1.5
454 Point X1 % 0.00 ... 100.00 14.1.1.1
455 Point Y1 % -100.00 ... 100.00 14.1.1.1
456 Point X2 % 0.00 ... 100.00 14.1.1.1
457 Point Y2 % -100.00 ... 100.00 14.1.1.1
Positioning
458 Operation mode - Selection 11.6
459 Signal Source - Selection 11.6.1
460 Positioning Distance U 0.000 ... 1 10
6
11.6.1
461 Signal Correction ms -327.68 ... 327.67 11.6.1
462 Load Correction - -32768 ... 32767 11.6.1
463 Activity after Positioning - Selection 11.6.1
464 Waiting Time ms 0 ... 3.6 10
6
11.6.1
Temperature Adjustment
465 Operation mode - Selection 17.7.2
466 Temperature Coefficient %/100 0.00 ... 300.00 17.7.2
467 Adjusting Temperature deg.C -50.0 ... 300.0 17.7.2
Positioning
469 Reference Orientation ° 0.0 ... 359.9 11.6.2
471 Positioning Frequency Hz 1.00 ... 50.00 11.6.2
472 Max positional error ° 0.1 ... 90.0 11.6.2
Motor Potentiometer
473 Ramp Keypad-Motorpoti Hz/s 0.01 ... 999.99 13.10
474 Operation mode - Selection 13.10
Frequency Reference Channel
475 Reference Frequency Source - Selection 13.4
Reference percentage channel
476 Reference Percentage Source - Selection 13.5
Percentage ramp
477 Gradient Percentage Ramp %/s 0 ... 60000 13.8
Technology Controller
478 Actual Percentage source - Selection 16.3
Positioning
479 time constant positioning controller ms 1.00 ... 9999.99 11.6.2
