Fixed Frequencies
No. Description Unit Setting range Chapter
480 Fixed Frequency 1 Hz -999.99 ... 999.99 13.6.1
481 Fixed Frequency 2 Hz -999.99 ... 999.99 13.6.1
482 Fixed Frequency 3 Hz -999.99 ... 999.99 13.6.1
483 Fixed Frequency 4 Hz -999.99 ... 999.99 13.6.1
489 JOG-Frequency Hz -999.99 ... 999.99 13.6.2
Speed Sensor 1
490 Operation mode - Selection 9.4.1
491 Division marks - 1 ... 8192 9.4.2
Repetition frequency input
496 Operation mode - Selection 13.11
497 Divider - 1 ... 8192 13.11
Logic Modules
503 Operation mode Logic 4 - Selection 14.5.3
504 Input 1 Logic 4 - Selection 14.5.3
505 Input 2 Logic 4 - Selection 14.5.3
Brake Chopper
506 Trigger Threshold V U
dmin
+25 ... 1000.0 17.4
Motor Chopper
507 Trigger Threshold V U
dmin
+25 ... 1000.0 17.7.1
Digital Outputs
510 Setting Frequency Hz 0.00 ... 999.99 14.3.1
Percentage Value Limits
518 Minimum Reference Percentage % 0.00 ... 300.00 13.3
519 Maximum Reference Percentage % 0.00 ... 300.00 13.3
Fixed Percentages
520 Fixed Percentage 1 % -300.00 ... 300.00 13.6.3
521 Fixed Percentage 2 % -300.00 ... 300.00 13.6.3
522 Fixed Percentage 3 % -300.00 ... 300.00 13.6.3
523 Fixed Percentage 4 % -300.00 ... 300.00 13.6.3
Digital Outputs
530 Op. Mode Digital Output 1 - Selection 14.3
532 Op. Mode Digital Output 3 - Selection 14.3
536 Create Warning Mask - Selection 14.3.7
540 Op. Mode Comparator 1 - Selection 14.5.2
541 Comparator On above % -300.00 ... 300.00 14.5.2
542 Comparator Off below % -300.00 ... 300.00 14.5.2
543 Op. Mode Comparator 2 - Selection 14.5.2
544 Comparator On above % -300.00 ... 300.00 14.5.2
545 Comparator Off below % -300.00 ... 300.00 14.5.2
549 Max. Control Deviation % 0.01 ... 20.00 14.3.2
Multifunctional output 1
550 Operation mode - Selection 14.2
551 Voltage 100% V 0.0 ... 24.0 14.2.1.1
552 Voltage 0% V 0.0 ... 24.0 14.2.1.1
553 Analog Operation - Selection 14.2.1
554 Digital Operation - Selection 14.3
555 Repetition Freq. Operation - Selection 14.2.2
556 Division marks - 30 ... 8192 14.2.2.1
Error/warning behavior
570 Motor Temp. Operation Mode - Selection 12.6
