Operating Instructions ACTIVE06/07 69
06/07 Operating Instructions ACTIVE 69
Key functions
ENT Reversal of the direction of rotation independent of the control signal on
the terminals Clockwise S2IND or Anticlockwise S3IND.
ESC Cancel function and return to the menu structure.
FUN Switch from internal set point int or rather motor potentiometer function
Pot to JOG frequency; the drive starts.
Release the key to switch to the sub-function and stop the drive.
RUN Start drive; alternative to control signal S2IND or S3IND.
STOP Stop drive; alternative to control signal S2IND or S3IND.
Attention! If you press the ENT key, the direction of rotation is changed inde-
pendent of the signal on the terminals Clockwise S2IND or Anticlockwise
S3IND.
If the
minimum frequency 418 has been set to 0.00 Hz, the direction
of rotation of the motor changes as soon as the sign of the reference
frequency value changes.
