2.6.2 DiBos micro
Electrical data
Compression technique MPEG4
Camera inputs (analog) 1 connecting cable with 6 BNC connectors (DB 06) or
2 connecting cables, each with 6 BNC connectors (DB 12)
Camera inputs (IP) 8 video/audio MPEG4 data streams from Bosch/VCS
network or JPEG units.
Composite video signal 1 Vpp +/-3 dB (min. 0.7 Vpp, max. 1.4 Vpp), 75 Ohm
Recording resolution (analog
inputs)
PAL:
704 x 576 (4CIF), 704 x 288 pixels (2CIF), 352 x 288 pixels
(CIF)
NTSC:
704 x 480 (4CIF), 704 x 240 pixels (2CIF), 352 x 240 pixels
(CIF)
Recording resolution (IP
inputs/Bosch IP devices)
PAL:
704 x 576 (4CIF/D1), 704 x 288 (2CIF), 464 x 576 (2/3
D1), 352 x 576 (1/2 D1), 352 x 288 (CIF), 176 x 144 (QCIF)
NTSC:
704 x 480 (4CIF/D1), 704 x 240 (2CIF), 464 x 480 (2/3
D1), 352 x 480 (1/2 D1), 352 x 240 (CIF), 176 x 120 (QCIF)
Recording rate (analog) for
DiBos micro models
IPS CIF
(PAL)
IPS CIF
(NTSC)
IPS 2CIF
(PAL)
IPS 2CIF
(NTSC)
IPS 4CIF
(PAL)
IPS 4CIF
(NTSC)
DB 06 C1 xxx Dx 75 90 50 60 25 30
DB 12 C2 xxx Dx 150 180 100 120 50 60
Recording rate per channel
(analog video inputs)
PAL:
0.5; 1; 2; 3; 4; 5; 6; 8; 12.5; 25 images per second
NTSC:
0.5; 1; 2; 3; 5; 6; 7.5; 10; 15; 30 images per second
Image size (analog video
inputs)
Configurable from approx. 1.5 kB to 30 kB (depending on
the changes in the image)
Maximum data storage rate
(analog and IP)
50 Mbit per second
Recording rate per channel
(IP video inputs)
PAL:
0.5; 1; 2; 3; 4; 5; 6; 8; 12.5; 25 images per second
NTSC:
0.5; 1; 2; 3; 5; 6; 7.5; 10; 15; 30 images per second
Image size (IP video inputs) Configurable up to 3 Mbit per camera
Supported single-channel
encoder (Bosch VideoJet
series and Bosch VIP series)
VideoJet 10S, VideoJet 1000
VIP X1, VIP 10, VideoJet X10
Supported multi-channel
encoder (Bosch VideoJet
series and Bosch VIP series)
VideoJet 8004, VideoJet 8004A, VideoJet 8008, VideoJet
8008A
VIP X2, VIP X2A, VIP X1600, VideoJet X20, VideoJet X40
Supported IP cameras from
Bosch
NWC-0455, NWC-0495, NWC-0700, NWC-0800, NWC-0900,
AutoDome IP, Flexidome IP
