40 en | Default Configuration DiBos/DiBos Micro
F.01U.033.308 | V7 | 2009.09 Installation Guide Bosch Sicherheitssysteme GmbH
6 Default Configuration
The default configuration allows more complex requirement or customer wishes to be catered
for than the Configuration wizard.
Go through the configuration tree from top to bottom by clicking individual menu points and
making the corresponding entries.
It is possible to switch to the Configuration wizard from the default configuration at any time;
however, this is only recommended for a newly installed system Section 5 Quick Configuration,
page 31.
6.1 Configuring Drives
Drives menu
This dialog box gives you an overview of the hard drives and network drives available.
CAUTION!
For security reasons, it is advisable to save the configuration on external data carriers.
1 The list field contains all hard drives and network drives
known to the system. The total size, the free storage capacity
and the used storage capacity are shown in MByte.
The drives listed can be activated or deactivated.
Activate the drive by clicking the check box.
The drive is activated.
The drive is not activated.
2 New network drive A new network drive can be added.
3 Disconnect network
drive
Disconnects a network drive. Select the drive and click the
button.
