DiBos/DiBos Micro Default Configuration | en 79
Bosch Sicherheitssysteme GmbH Installation Guide F.01U.033.308 | V7 | 2009.09
6.5.6 Configuring Foyer Card Readers
Inputs and outputs menu > Foyer card reader tab
A maximum of 4 foyer card readers can be connected to one video system. Each foyer card
reader uses one input. Anti-skimming is possible on the foyer card reader.
NOTICE!
You may not configure more foyer card readers than the number connected.
1 Foyer card reader Click the tab.
2 Interface: Select the interface.
3 Type Click the down arrow in the column and select
whether an input is to be configured or not.
A foyer card reader is connected to the input.
No foyer card reader is connected to the input.
4 Name Place the cursor in the column and enter the name.
The name can be freely selected.
