54 en | Default Configuration DiBos/DiBos Micro
F.01U.033.308 | V7 | 2009.09 Installation Guide Bosch Sicherheitssysteme GmbH
6.2.7 Editing Audio Settings
Video and audio connections menu > Audio input section > Edit button
Here you can edit the names and the audio level of each individual audio input.
1 Name: The name of the audio input is displayed and can be edited.
2 Audio level: The audio level of the audio input can be changed with the
slider.
Note:
Slider all the way left = minimum audio level
Slider all the way right = maximum audio level
3 Signal level Shows the signal level selected with the slider graphically.
From the color, you can see if the sound is being received
without distortion or if you need to change the audio level.
Green = sound is too soft
Yellow = sound is optimally set
Red = sound is overamplified
4 OK The entries are saved.
