DiBos/DiBos Micro Default Configuration | en 97
Bosch Sicherheitssysteme GmbH Installation Guide F.01U.033.308 | V7 | 2009.09
6.8 Configuring Alarm Transmission
Alarm transmission menu
In this dialog box you can specify jobs for alarm transmissions. Jobs are activities that are
started by inputs and cameras with motion detection.
In the event of an alarm, a connection is established from the station generating the alarm to
the configured remote station.
In the remote station live image, the tab blinks red. The remote station generating
the alarm is displayed by clicking the tab. Clicking the remote station shows the cameras that
have been triggered.
1Job
Add Adds a new job. The name of the new job is sequentially
numbered and can be renamed.
Remove Removes a job. To do so, select the job.
Rename The name of the job can be changed. To do so, select the job.
