Programmable Outputs
The control panel has four fully programmable outputs on the main printed circuit board and
one programmable output that operates the codepad buzzer. The four outputs are set by
default to operate as an alarm device, fire alarm verification, strobe, and internal screamer.
The control panel supports additional 16 outputs via two output expanders.
Programmable outputs require four parameters to operate correctly.
Parameter Description
Event Type The Event Type specifies when an output is activated. Enter the
code for the Output Event Type into the two corresponding
locations for the output.
Polarity Polarity determines whether the output operates for the duration
of the event, pulses for the duration, operates only once (one
shot), or latches on.
Time Base/Time
Multiplier
The Time Base and Time Multiplier parameters determine how
long and how often the output operates.
Table 16.1: Output Parameters
Output Programming
Item Location Default New Item Location Default New
Output 1 (Default = Horn Speaker) Output 2 (Default = Fire Alarm With Verification)
Event Code 0436 1 Event Code 0442 2
Event Code 0437 14 Event Code 0443 7
Polarity 0438 0 Polarity 0444 10
Time Base 0439 0 Time Base 0445 2
Time Base Multiplier 0440 0 Time Base Multiplier 0446 1
Time Base Multiplier 0441 0 Time Base Multiplier 0447 5
Output 3 (Default = Strobe – Reset After 8 hrs.) Relay Output (Default = Sirens Running)
Event Code 0448 2 Event Code 0454 1
Event Code 0449 0 Event Code 0455 15
Polarity 0450 6 Polarity 0456 1
Time Base 0451 4 Time Base 0457 0
Time Base Multiplier
0
452
0 Time Base Multiplier 0458 0
Time Base Multiplier 0453 8 Time Base Multiplier 0459 0
Codepad Buzzer (Default = Entry/Exit Warning and
Day Alarm)
Event Code 0460 0
Event Code 0461 13
16
16.1
Control Panel Programmable Outputs | en 117
Bosch Security Systems, Inc. Installation Guide 2017.10 | 03 | F.01U.298.026
