When the Zone Type is programmed as keyswitch, Zone Options 1 replaces Keyswitch Zone
Options. A keyswitch zone can arm/disarm or momentary arm/disarm the area in STAY Mode 1
or AWAY Mode as configured. A keyswitch zone can only arm/disarm the area it belongs to. Its
zone number is reported as a user code number.
TF008 Plug Pack (TF008-B)
The TF008 plug pack is used with control panels.
The plug pack includes built-in thermal fuses that blow during overload or fault conditions to
eliminate a possible fire threat due to excessive heat buildup inside the casing.
The plug pack incorporates a three-wire flying lead that enables a MAINS earth connection
between the equipment and the plug pack. This connection might be required for lightning
protection on equipment connected to phone lines or for safety reasons such as earthing of
metal enclosures.
Install the transformer
Caution!
Do not short-circuit the terminals of the transformer: Shorting the terminals opens the
internal fuse, causing permanent failure. Connect the transformer to the 18-22 VAC terminals
of the control panel before plugging it into the power source.
Notice!
Plan Ahead
Route telephone, SDI2 bus wiring, and sensor loop wiring away from any AC conductors,
including the transformer wire. AC wiring can induce noise and low level voltage into adjacent
wiring.
1. Use 18 AWG (1.02 mm) wire minimum (12 AWG [2 mm] maximum) and connect the
transformer to the control panel. Make the wire length as short as possible. Do not
exceed 50 ft (15 m).
2. Connect the wire to the control panel.
3. Connect the wire to the transformer.
4. Plug the transformer into the power outlet.
DLA
Direct link adapter IUI-SOL-ADAPTER is one of accessories that can be used in conjunction
with the SDI2 Bus control panel.
DLA works with control panel via SDI2 bus cable.
– Copy the control panel memory to the DLA.
– Copy the DLA data to the control panel memory.
– Control panel firmware upgrade.
A-Link Plus controls the control panel remotely via DLA.
4.15
4.15.1
4.16
24 en | Accessories Control Panel
2017.10 | 03 | F.01U.298.026 Installation Guide Bosch Security Systems, Inc.
