Communication Information
This section outlines the programming information required for the control panel when
communicating with a base station receiver. These parameters specify the telephone numbers
to call, transmission formats, and transmission speeds.
The control panel can report event information from two on-board communicators / modules.
The first communicator reports to Receiver 1 and 2 and the second communicator reports to
Receiver 3 and 4.
When only one communicator is used, the communicator reports to Receiver 1/2/3/4.
You can program each communicator with two separate telephone numbers, reporting format
type, and Subscriber ID Number.
Example
You can set up Communicator 1 to notify alarms in Domestic Dialing Format to Receiver 1 and
set up Communicator 2 to report to a base station receiver in Contact ID Format only if
Communicator 1 is unsuccessful.
To program a telephone number:
When programming a telephone number, you can program a 0 as a 0. Each location in the
primary, secondary, and callback telephone numbers stores one digit of the telephone
number.
You must insert a terminator (15) at the end of a telephone number to indicate to the
communicator the end of the telephone number is reached. The dialing sequence terminates
when a 15 appears.
Example
To program the telephone number 9672 1055 as the Primary Telephone Number for Receiver
1, program the following sequence into Locations 000 to 015: [9 6 7 2 1 0 5 5 15 15 15 15 15
15 15 15]
To enter a 4-sec pause in the dialing sequence, program a 13. A pause might be necessary
when the module communicates through an old (slower) telephone exchange or when a PABX
system is in place.
Example
To program the number 02 pause 9672 1055, enter: [0 2 13 9 6 7 2 1 0 5 5 15 15 15 15 15].
How to program the numbers, keys, and functions for a telephone number, refer to below
table.
Digit Required
Number to Program Digit Required Number to Program
0 0 8 8
1 1 9 9
2 2
3 3 * * 1
4 4 # * 2
5 5 4-sec Pause * 3
6 6
7 7 Terminator * 5
Table 11.1: Dialing Digits
11
68 en | Communication Information Control Panel
2017.10 | 03 | F.01U.298.026 Installation Guide Bosch Security Systems, Inc.
