7-2
Confidential
Open Twice Once 17) Printing for Maintenance 7-10
Twice 18) Maintenance + Test
pattern with margin frame
(DX/LongBind)
7-12
Three times 19) Network Config Printing 7-12
Four times 20) Sleep Mode Setting (ON/
OFF)
7-12
Five times Ineffective
Six times 21) Developer Roller Counter
Reset 2 (For the Standard
toner cartridge)
7-13
Seven times 21) Developer Roller Counter
Reset 3 (For the High-
capacity toner cartridge)
7-13
Eight times 22) Fixed USB Speed Mode 7-13
Nine times 23) USB Speed Indication (ON/
OFF)
7-14
Ten times 24) Sleep Mode Indication
(OFF/Dimmed)
7-15
More than 11 times Go back to Normal State
Three times Once Factory use
Twice Factory use
Three times Factory use
Four times Factory use
Five times Factory use
Six times Factory use
Seven times Factory use
Eight times Factory use
Nine times 25) Inspection Mode
Clearance + Inspection
Mode Mask
7-15
Ten times Factory use
11 times Factory use
12 times Factory use
More than 13 times Go back to Normal State
Four times 0 times Ineffective
Five times Once Factory use
More than six times Ineffective
More than 2 seconds (long push) 26) PIT3 Inspection Mode 7-15
Front
cover
Press the [Go] button
when sifting the mode
Press the [Go] button
when selecting the
function
Function
Refer
to:
