Page #134 background imageLoading...
Page #134 background image
3-43
Confidential
â–  Paper jam in the back cover and paper eject section
â–  Paper jam in the tray 2
â–  Paper jam in the Duplex unit section
Step Cause Check
Result
Remedy
1
Foreign object
around fuser unit
Is there a foreign object
around the fuser unit?
Yes
Remove the foreign
object.
2
Paper eject
actuator failure
Does the paper eject
actuator move smoothly?
Is it damaged?
No
Replace the paper eject
actuator.
3
Fuser cover ASSY
loose
Is the fuser cover ASSY
fitted correctly?
No
Fit the fuser cover ASSY
correctly.
4
Outer chute ASSY
loose
Is the outer chute ASSY
fitted correctly?
No
Fit the outer chute ASSY
fitted correctly.
5
Eject roller 1
malfunction
Is the eject roller 1 of the
rear chute ASSY attached
to the pinch roller
properly?
No
Replace the rear chute
ASSY.
6
Paper eject
sensor failure
Is the problem solved
after replacing the relay
rear PCB?
Yes
Replace the relay rear
PCB ASSY.
7
Main PCB failure Is the problem solved
after replacing the Main
PCB ASSY?
Yes
Replace the Main PCB
ASSY.
Step Cause Check
Result
Remedy
1
LT edge actuator
catching on some
position
Does the LT edge
actuator move smoothly? No
Re-assemble the LT edge
actuator.
2
LT sensor PCB
ASSY failure
Is the problem solved
after replacing the LT
sensor PCB ASSY?
Yes
Replace the LT sensor
PCB ASSY.
3
LT solenoid failure Is the problem solved
after replacing the LT
solenoid?
Yes
Replace the LT solenoid.
Step Cause Check
Result
Remedy
1
Duplex unit failure Is the problem solved
after replacing the Duplex
unit?
Yes
Replace the Duplex unit.
