Brother MFC-8480DN - B/W Laser - All-in-One User Manual

7-4
Confidential
4. DETAILED DESCRIPTION OF
MAINTENANCE-MODE FUNCTIONS
4.1 EEPROM Parameter Initialization (Function code 01/91)
<Function>
The machine initializes the parameters, user switches, and firmware switches registered in
the EEPROM, to the initial values. Entering the function code 01 initializes all of the
EEPROM areas, but entering 91 does not initialize some areas, as listed below.
<Operating Procedure>
(1) Press the [0] and [1] keys (or the [9] and [1] keys according to your need) in this order in
the initial stage of the maintenance mode.
The "PARAMETER INIT" will appear on the LCD.
(2) Upon completion of parameter initialization, the machine returns to the initial stage of the
maintenance mode.
(3) Press the [9] key twice to exit from the maintenance mode.
(4) Turn the machine power off.
Note:
• If you replace the main PCB with the one used for any other machine, customize the
EEPROM (maintenance mode function code 74 in Section 4.18.) and then carry out
this procedure.
Function code
Data item
01 91
Maintenance-mode functions
User switches
Firmware switches
Remote activation code
Station ID data
Outside line number
Telephone function registration
One-touch dialing
Speed dialing
Group dialing
All of these will
beinitialized.
These will be
initialized.
These will not
be initialized.
These will not
be initialized.

Brother MFC-8480DN - B/W Laser - All-in-One Specifications

General

Printer Type	B/W Laser
Functions	Print, Copy, Scan, Fax
Scan Resolution	Up to 19200 x 19200 dpi (interpolated)
Automatic Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet
Paper Input Capacity	250 sheets
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Print Speed	32 ppm
Copy Resolution	1200 x 600 dpi
Scan Type	Flatbed, ADF
Max Paper Size	Legal (8.5 in x 14 in)
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 32 cpm
Dimensions	531 mm x 451 mm x 475 mm
