5-6
Confidential
4. SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening
torque
N · m (kgf · cm)
CCD
model
CIS
model
FU harness cover 1 Taptite pan B M4x20 1 0.7±0.1 (7±1)
Fuser unit Taptite pan B M4x20 1 0.7±0.1 (7±1)
Process cover stopper Taptite cup B M4x10 1 0.5±0.1 (5±1)
Emblem cover Taptite cup B M3x10 2 0.5±0.1 (5±1)
Side cover L Taptite bind B M4x12 2 0.7±0.1 (7±1)
Shield cover ASSY
(FG harness)
Taptite cup S M3x6 SR 4 0.75±0.1 (7.5±1)
CCD
model
ADF FG harness Taptite cup S M3x6 1 0.7±0.05 (7±0.5)
Hinge base R Taptite cup B M3x10 2 0.8±0.1 (8±1)
Hinge ASSY L
Taptite cup B M3x10 2 0.5±0.1 (5±1)
Taptite cup S M3x12 1 0.7±0.1 (7±1)
ADF side cover F
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Taptite cup S M3x8 1 0.5±0.1 (5±1)
ADF side cover R
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
ADF chute ASSY Taptite cup B M3x10 5 0.5±0.1 (5±1)
SX Chute Taptite cup S M3x8 2 0.5±0.1 (5±1)
Exit chute cover ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
ADF motor
Screw, pan (S/P
washer) M3X6
2
0.7±0.1 (7±1)
Motor frame ASSY Taptite cup S M3x8 3 0.7±0.05 (7±0.5)
Switch back solenoid ASSY Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
PF solenoid ASSY Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
ADF relay PCB Taptite cup S M3x8 1 0.7±0.05 (7±0.5)
Paper feed plate Taptite cup S M3x8 2 0.7±0.05 (7±0.5)
Paper feed chute ASSY Taptite cup S M3x8 2 0.7±0.05 (7±0.5)
Separation rubber Taptite B M3x6 1 0.4±0.05 (4±0.5)
Drive frame sub ASSY DX Taptite cup B M3x10 3 0.5±0.1 (5±1)
Front frame Taptite cup B M3x10 3 0.5±0.1 (5±1)
Upper main chute ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
Rear sensor cover Taptite cup B M3x10 2 0.5±0.1 (5±1)
LF spring Taptite cup B M3x10 2 0.5±0.1 (5±1)
CIS
model
FG harness Taptite cup S M3x6 SR 2 0.75±0.1 (7.5±1)
Shield cover ASSY Taptite cup S M3x6 SR 2 0.75±0.1 (7.5±1)
ADF FG harness Taptite cup S M3x6 1 0.7±0.05 (7±0.5)
ADF unit Taptite bind B M4x12 2 0.8±0.1 (8±1)
Hinge ASSY Taptite cup S M3x10 3 0.9±0.05 (9±0.5)
ADF gear cover Taptite cup B M3x10 1 0.5±0.1 (5±1)
