5-7
Confidential
CIS
model
ADF chute ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
ADF FG harness Taptite cup S M3x6 SR 1 0.7±0.1 (7±1)
ADF relay PCB ASSY Taptite cup S M3x6 SR 1 0.7±0.05 (7±0.5)
Motor frame ASSY
Taptite cup S M3x6 SR 3 0.7±0.05 (7±0.5)
Taptite cup S M3x10 1 0.7±0.05 (7±0.5)
Pickup solenoid ASSY Taptite cup S M3x6 SR 1 0.7±0.05 (7±0.5)
ADF motor
Screw pan (S/P
washer) M3x6 DB
2 0.7±0.1 (7±1)
Exit solenoid ASSY Taptite cup S M3x6 SR 1 0.7±0.05 (7±0.5)
Lower document chute ASSY Taptite cup B M3x10 4 0.5±0.1 (5±1)
Separate roller holder ASSY Taptite cup B M3x10 1 0.8±0.1 (8±1)
Support plate Taptite cup B M3x6 3 0.5±0.1 (5±1)
Document exit tray sensor
cover ASSY
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Document exit tray roller holder
ASSY
Taptite cup B M3x10 1 0.5±0.1 (5±1)
Upper document sub chute Taptite cup B M3x10 2 0.5±0.1 (5±1)
Gear 34 Taptite cup B M3x10 1 0.5±0.1 (5±1)
Exit chute Taptite bind B M4x10 1 0.7±0.05 (7±0.5)
CCD
model
Document scanner unit Taptite cup B M4x20 2 0.8±0.1 (8±1)
Scanner top cover ASSY Taptite cup B M4x12 6 0.8±0.1 (8±1)
Lock lever B Taptite B M3x6 1 0.4±0.05 (4±0.5)
Lock lever A Taptite B M3x6 2 0.4±0.05 (4±0.5)
FB FG harness Taptite cup S M3x6 1 0.8±0.1 (8±1)
Drive plate ASSY Taptite B M3x8 4 0.5±0.1 (5±1)
Scanner motor FB
Screw, pan (S/P
washer) M3X6
2 0.7±0.1 (7±1)
Pulley ASSY Taptite B M3x6 2 0.4±0.05 (4±0.5)
CIS
model
FB FG harness Taptite cup S M3x6 1 0.8±0.1 (8±1)
CCD
model
Panel unit ASSY Taptite cup B M4x12 4 0.7±0.1 (7±1)
Panel bottom cover Taptite cup B M3x10 4 0.5±0.1 (5±1)
NCU FG harness ASSY
Screw, pan (S/P
washer) M3.5X6 SR
1 0.4±0.05 (4±0.5)
NCU shield plate Taptite bind B M4x12 2 0.8±0.1 (8±1)
NCU shield cover
Screw, pan (S/P
washer) M3.5X6
1 0.4±0.05 (4±0.5)
NCU PCB ASSY Taptite cup S M3x6 2 0.5±0.05 (5±0.5)
Location of screw Screw type Q’ty
Tightening
torque
N · m (kgf · cm)
