5-8
Confidential
CIS
model
NCU cover Taptite bind B M4x12 4 0.8±0.1 (8±1)
NCU shield Taptite bind B M4x12 2 0.8±0.1 (8±1)
NCU FG harness ASSY
Screw, pan (S/P
washer) M3.5X6
1 0.4±0.05 (4±0.5)
NCU PCB ASSY Taptite cup S M3x6 SR 2 0.5±0.05 (5±0.5)
CCD
model
Speaker hold spring Taptite bind B M4x12 1 0.8±0.1 (8±1)
Driver PCB shield
Taptite cup B M3x8 2 0.4±0.05 (4±0.5)
Taptite cup S M3x6 SR 1 0.75±0.1 (7.5±1)
CIS
model
Driver PCB Taptite cup S M3x6 SR 2 0.6±0.1 (6±1)
CCD
model
USB HOST FG harness ASSY Taptite bind B M4x12 1 0.8±0.1 (8±1)
USB PCB holder Taptite bind B M4x12 1 0.8±0.1 (8±1)
USB HOST PCB ASSY Taptite cup S M3x6 SR 1 0.9±0.1 (9±1)
Side cover R Taptite bind B M4x12 2 0.7±0.1 (7±1)
Joint cover ASSY Taptite bind B M4x12 4 0.8±0.1 (8±1)
CIS
model
Joint cover FR Taptite bind B M4x12 1 0.8±0.1 (8±1)
Joint cover FL Taptite bind B M4x12 1 0.8±0.1 (8±1)
USB PCB holder Taptite cup B M3x10 2 0.5±0.1 (5±1)
USB HOST PCB ASSY Taptite cup S M3x6 SR 1 0.9±0.1 (9±1)
Inner chute Taptite bind B M4x12 4 0.8±0.1 (8±1)
Location of screw Screw type Q’ty
Tightening
torque
N · m (kgf · cm)

Brother MFC-8480DN - B/W Laser - All-in-One Specifications

General

Printer Type	B/W Laser
Functions	Print, Copy, Scan, Fax
Scan Resolution	Up to 19200 x 19200 dpi (interpolated)
Automatic Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet
Paper Input Capacity	250 sheets
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Print Speed	32 ppm
Copy Resolution	1200 x 600 dpi
Scan Type	Flatbed, ADF
Max Paper Size	Legal (8.5 in x 14 in)
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 32 cpm
Dimensions	531 mm x 451 mm x 475 mm
