<WSW24> (TAD setting 2)
• Selectors 3 and 4: Time length from CML ON to start of pseudo ring backtone
transmission
These selectors set the length of time from CML-ON up to the start of pseudo ring
backtone transmission.
In models with OGM facilities, the settings made by these selectors also apply to the length
of time from CML-ON up to the start of OGM transmission.
<WSW25> (TAD setting 3)
• Selectors 3 and 4: External TAD no-tone detection level
These selectors set the no-tone detection level in the external TAD mode.
Selector No. Function Setting and Specifications
1
2
Maximum OGM recording time
(Not used.)
3
4
Time length from CML ON to
start of pseudo ring backtone
transmission
No. 3 4
00: 4 sec.
01: 3 sec.
10: 2 sec.
11: 1 sec.
5
I
8
Attenuator for playback of ICM/
OGM to the line
(Not used.)
Selector No. Function Setting and Specifications
1
2
Not used.
3
4
External TAD no-tone detection
level
No. 3 4
0 0: -43 dB (A)
0 1: -46 dB (B)
1 0: -49 dB (C)
1 1: -51 dB (D)
5
I
7
Pause between paging number
and PIN (Not used.)
8 Not used.
Note:
• Selectors 5 through 7 are applicable to the U.S.A. models only.
