Brother MFC-J2330DW

3-54
Confidential
Assembling Note: Assemble a new Second side CIS flat cable by bending the
Second side CIS flat cable and affixing the Double-sided adhesive
tape as shown in the figure below.
Fig. 3-42
Terminal
Terminal
Double-sided
adhesive tape
Double-sided
adhesive tape
12
981±10
10
mm
45°±3.5°
45°±3.5°
45°±3.5°
45°±3.5°
0 to 5
Supporting tape
Supporting tape
mm
mm
Insulating
tape
±2
mm
To CIS unit
To main body
12mm
To main body
Mountain fold
Valley fold
45°±3.5°
45°±3.5°
160.5±2
mm
15±1
mm
290±2
mm
83±1
mm
235±1
mm
13±2mm
50±2mm
200±5
mm
2±1.5mm
17±2mm
378±5
mm
14mm
or less
Insulating
tape
Double-sided
adhesive tape
Double-sided
adhesive tape
12mm
12mm
