6-4 Confidential
(4) Remove all four ink cartridges and set the protective part instead.
(6_02_J)
Ink cartridges
Ink cartridge cover
Protective part
îš„ How to Access the Target Component
• On the next page is a disassembly flowchart which helps you access the target components. To
remove the maintenance unit, first find it on the flowchart and note its number (
in this case).
To access it, you need to remove all the parts above the maintenance unit on the flowchart ( ,
,
, ,
and in this case) before the unit itself can be removed.
• Unless otherwise specified, all parts should be replaced in the opposite order to which they were
removed to reassemble the machine.
To Next Page
