9.1.2 List of Functions in the Machine Maintenance Mode
Maintenance-mode Functions
Function
Code
Function
Reference
Section (Page)
01 EEPROM Parameter Initialization 9.1.4.1 (9-4)
05 Printout of Scanning Compensation Data 9.1.4.2 (9-5)
08 ADF Performance Test 9.1.4.3 (9-7)
09 Test Pattern 9.1.4.4 (9-8)
10 Firmware Switch Setting 9.1.4.5 (9-10)
11 Printout of Firmware Switch Data 9.1.4.5 (9-13)
12 Operational Check of LCD 9.1.4.6 (9-15)
13 Operational Check of Control Panel PCB
(Check of Keys)
9.1.4.7 (9-16)
32 Sensor Operational Check 9.1.4.8 (9-18)
53 Transfer of Received FAX Data and/or Equipment's Log 9.1.4.9 (9-20)
54 Fine Adjustment of Scanning Start/End Position 9.1.4.10 (9-22)
55 Acquisition of White Level Data and CIS Scanner Area Setting 9.1.4.11 (9-23)
58 Updating of Paper Feeding Correction Value 9.1.4.12 (9-24)
59 Checking of CIS Travel and Specifying of CIS Type 9.1.4.13 (9-28)
63 Travel Check of the Head/Carriage Unit and Initial Setup Mode 9.1.4.14 (9-30)
65 Alignment of Vertical Print Lines in Monochrome 9.1.4.15 (9-31)
66 Margin Adjustment in Borderless Printing 9.1.4.16 (9-33)
68 Updating of Property Data 9.1.4.17 (9-36)
69 Head/Carriage Unit Traveling Speed Check 9.1.4.18 (9-37)
74 EEPROM Customizing 9.1.4.19 (9-38)
75 Travel of Head/Carriage Unit (for removing paper particles and
dust accumulated on the maintenance unit)
9.1.4.20 (9-41)
76 Purging Operation 9.1.4.21 (9-42)
80 Display of the Equipment's Log 9.1.4.22 (9-45)
82 Equipment Error Code Indication 9.1.4.23 (9-47)
87 Output of Transmission Log to the Telephone Line 9.1.4.24 (9-47)
88 Assurance Mode Switch Setting 9.1.4.25 (9-48)
91 EEPROM Parameter Initialization (except the telephone number
storage area)
9.1.4.1 (9-4)
99 Exit from the Maintenance Mode ----- (9-1)
(Menu + #, 2, 7,
9, 0, 0)
Cancellation of the Pin TX Lock Mode (Not applicable to
U.S.A. models)
9.1.4.26 (9-55)
