9-7 Confidential
9.1.4.3 ADF Performance Test (Function code 08)
îš„ Function
The machine counts the documents fed by the automatic document feeder (ADF) and displays the
count on the LCD for checking the ADF performance.
îš„ Operating Procedure
(1) Set documents. (Allowable up to the ADF capacity.)
The "DOC. READY" appears on the LCD.
(2) Press the 0 and 8 keys in this order in the initial stage of the maintenance mode.
The machine feeds the documents in and out while counting them and displaying the current
count on the LCD as shown below.
ADF CHECK P.01
Current count (1st page in this example)
(3) After counting all documents, the machine shows the final count. To return the machine to the
initial stage of the maintenance mode, press the Stop/Exit key.
To Next Page
