6-34
Confi
denti
al
îš„
Asse
m
bl
i
ng N
otes
•
R
out
e th
e an
te
nn
a w
i
r
e as
sh
own
belo
w
.
(6_30_3_e)
Antenna wire
Speaker harness
Upper cover
Antenna support
Antenna & cordless PCB ASSY
Pass the antenna wire through
this guide provided on the
antenna support.
Route the antenna wire
between these two ribs.
Plate spring
192
