Brother MFC260C User Manual

1-16 Confidential
1.3 COMPONENTS
The machine consists of the following major components:
Color LCD
unit
Control panel
ASSY
Wide color LCD type
ADF & document cover ASSY (For models with ADF)
Document cover (For models without ADF)
Scanner cover
(Scanner unit)
Scanner cover
damper
Scanner cover
support
Upper cover*
Upper cover* *
Head/carriage
unit
Engine unit
PF encoder PCB
Registration sensor
PCB
Flushing box
Lower cover
Power supply PCB
MJ/PS shield box
Paper tray ASSY
Ink absorber box
Main PCB ASSY
Ink refill ASSY
Maintenance unit
Front cover
Ink cartridge cove
r
Media module cover
WLAN PCB*
Cover sensor PCB
Control panel
ASSY
Color LCD
unit
Control panel
ASSY
Color LCD type
Monochrome LCD type
(COMPONENTS_MFC_e)
MJ PCB
Handset mount*
1
Handset*
1
Charge stand
ASSY*
2
Hook switch PCB*
1
4
Speaker
Jam clear cover
Cordless
handset*
2
Antenna & cordless
PCB ASSY*
2
12
3
*
1
For models with handset
*
2
For models with cordless handset
*
3
For models without handset and
cordless handset
*
4
For wireless LAN-enabled models
