9-12 Confidential
îš„ Operating Procedure
(1) Press the 1 and 0 keys in this order in the initial stage of the maintenance mode.
The machine displays the "WSW0
0" on the LCD and becomes ready to accept a firmware
switch number.
(2) Enter the desired number from the firmware switch numbers (01 through 59).
The following appears on the LCD:
Selector 1 Selector 8
↓ ↓
WSWXX = 0 0 0 0 0 0 0 0
(3) Use the right and left arrow keys to move the cursor to the selector position to be modified.
(4) Enter the desired number using the 0 and 1 keys.
(5) Press the OK key. This operation saves the newly entered selector values onto the EEPROM
and readies the machine for accepting a firmware switch number.
(6) Repeat steps (2) through (5) until the modification for the desired firmware switches is
completed.
(7) Press the Stop/Exit key to return the machine to the initial stage of the maintenance mode.
NOTES: • To cancel this operation and return the machine to the initial stage of the maintenance
mode during the above procedure, press the Stop/Exit key.
• If there is a pause of more than one minute after a single-digit number is entered for
double-digit firmware switch numbers, the machine will automatically return to the
initial stage of the maintenance mode.
îš„ Details of Firmware Switches
The details of the firmware switches are described in Appendix 4 in which the user-accessible
selectors of the firmware switches are shaded
.
To Next Page
