9-44 Confidential
îš„ Resetting purge or flushing counter
1) Press the Menu and Black Start (Mono Start) keys. Next press the key four times to
make the machine enter the maintenance mode.
The machine beeps for approx. one second and displays " " on
the LCD, indicating that it is placed in the initial stage of the maintenance mode, a mode in
which the machine is ready to accept entry from the keys.
2) Press the 8 and 0 keys in this order in the initial stage of the maintenance mode to call up
the machine's log information. (Function code 80. Refer to Section 9.1.4.22.)
3) Press the Black Start (Mono Start) key several times until the purge or flushing count
appears on the LCD.
4) Press the 2, 7, 8, and 3 keys in this order to reset the purge or flushing count.
5) Press the Stop/Exit key to return the machine to the initial stage of the maintenance mode.
6) Press the 9 key twice to return to the standby state.
