S-7300A
3. FUNCTION SETTINGS
17
No. Setting range
Initial
value
Setting
units
Setting details
564
OFF,
1～240
(seconds)
180
(seconds)
1
Presser foot lifting time
OFF: No timer function (no dropping)
1 to 240: Presser foot dropping after setting time
565
10
～
60
(%)
25
(%)
1 On duty when solenoid-type presser lifter is chopping control
(*) This is displayed when MSW-550 is set to "0".
566
10
～
60
(%)
50
(%)
1 On duty when pneumatic-type presser lifter is chopping control
(*) This is displayed when MSW-550 is set to "1".
567
0
～
1
0
1
Control for presser foot lowering
0: Control P/F lowering timing with detected voltage of P/F lifter solenoid by
MSW-569
1: Control timing for P/F lifter solenoid lowering by MSW-568
568
20
～
120
(ms)
40
(ms)
5
(ms)
Delay time for presser foot lifter solenoid to turn on after presser foot drop
signal
(*) Displayed when MSW-567 is set to "1".
569
10
～
15
12
1
Voltage detection constant for presser foot lifter solenoid to turn on after
presser foot drop signal
(*) Displayed when MSW-567 is set to "0".
If it is set to "10", the response will be fastest and the operating noise
will be loudest.
