II - 4
2.1.4 Cover Open Sensor
The cover open sensor is mounted in the upper cover. By closing the roll cover,
section “A” of the roll cover inner presses the switch of the cover open sensor, and
transmits the “roll cover closed” signal.
Figure 2.1-4 Cover Open Sensor
Roll cover
Section “A”
Cover open sensor
