Brother TD-2020 - 13 ]Removing the Upper Cover

III - 19
[ 13 ]Removing the Upper Cover
(1) Remove the four taptite bind B M2.6X8 screws. Release the two hooks to
remove the upper cover from the mecha ASSY.
Figure 3.4-17
Upper cover
Taptite bind B M2.6X8
Taptite bind B M2.6X8
Taptite bind B
M2.6X8
Hooks
Mecha ASSY
