III - 40
[ 11 ] Attaching the Roll Cover Outer A
(1) Set the roll cover outer A to the roll cover inner, and secure it with four taptite bind
B M2.6X8 screws.
Figure 3.5-15
Taptite bind B M2.6X8
Roll cover outer A
Roll cover
inner
