Brother TD-2020 - 2 ] Removing the Bottom Cover B, Front Cover, and Bottom Cover a

III - 4
[ 2 ] Removing the Bottom Cover B, Front Cover, and Bottom Cover A
(1) Turn the machine upside down.
(2) Remove the four taptite bind B M2.6X6 screws to remove the bottom cover B
from the machine.
(3) Remove the four taptite bind B M2.6X8 screws from the bottom cover A.
Figure 3.4-2
Bottom cover B
Taptite bind B M2.6X6
Taptite bind B M2.6X8
Taptite bind B M2.6X8
Bottom cover A
