Brother TD-2020 Service Manual

1 - 2
1.2 Serviceman Tool
1.2.1 Role of the Serviceman Tool
Serviceman tool serves to check the operation of each function, and writes the setting value or
serial number into the machine. After repair, be sure to use the tool to implement the required
inspection items. This tool is unable to check the Wired LAN, Wireless LAN, and BT
communications, or other optional products. Note that separate inspections are required for
each of them as needed.
This tool supports:
• TD-2020 (hereinafter referred to as "TD-2000")
• TD-2120N / 2130N (hereinafter collectively referred to as "TD-2100N").
Models and the corresponding tools are described in the table below. Inspections are
inoperable with wrong combination.
Correspondence table
Tool Model
TD2020SE TD-2020
TD2120NSE TD-2120N
TD2130NSE TD-2130N

Brother TD-2020 Specifications

General

Color	-
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	98.6 mm
Maximum printing width	56 mm
Product color	White
USB port	Yes
Ethernet LAN	No
Optional connectivity	Serial (RS-232), USB 2.0
USB 2.0 ports quantity	1
Connectivity technology	Wired
Flash memory	8 MB
Tape cutting	Automatic
Internal memory	6 MB
Number of fonts	7
Built-in barcodes	QR Code
Page description languages	ESC P
Maximum label length	1 m
Cables included	USB
Character sets	Abicomp, ASCII, BRASCII, ISO 8859-15, ISO Latin 1, Italic, PC437, PC850, PC858, PC860, PC861, PC863, PC865, Roman 8
Minimum RAM	128 MB
Minimum storage drive space	70 MB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433210
Package weight	2833 g
AC adapter output current	6 A
AC adapter output voltage	25 V

Weight and Dimensions

Depth	215 mm
Width	110 mm
Height	172 mm
Weight	1320 g
