III - 3
3.4 DISASSEMBLY PROCEDURE
[ 1 ] Preparation
(1) Press the power button to turn OFF the main power switch.
(2) Disconnect all cables connected to the machine.
(3) Lift the release lever to open the roll cover ASSY. Remove the thermal tape and
close the roll cover ASSY.
Figure 3.4-1
Thermal tape
Roll cover ASSY
Release lever
Power button
