Brother TD-2020 - Page 19

III - 5
(4) Turn the machine upside down.
(5) Lift the release lever to open the roll cover ASSY.
(6) Remove the two taptite bind B M2.6X8 screws from the front cover. Push the
bottom cover A outward to remove the front cover.
Figure 3.4-3
Roll cover ASSY
Front cover
Taptite bind B M2.6X8
Bottom cover A
Release lever
