III - 6
(7) Push the bottom cover A outward to remove it from the machine. Remove the
guide shaft from the machine and close the roll cover ASSY.
(8) Remove the four lower foots from the bottom cover A.
Figure 3.4-4
Roll cover ASSY
Bottom cover A
Lower foots
Guide shaft
Lower foots
