Bruker M4 TORNADO - Table 11 Generation of Connection between Instrument and Instrument PC (Windows 7)

The M4 TORNADO Software
M4 TORNADO
45
Table 11 Generation of connection between instrument and instrument PC (Windows
®
7)
Dialog Description
Selection of Network connections on the
PC
Select Local Area connections
Select properties
Select the Internet Protocol Version 4
(TCP/IPv4)
Use the following addresses:
IP address: 192.168.10.1
sub net mask: 255.255.255.0
For definition of the address of the instrument go to the System workspace and select the
System button.
