Using the M4 TORNADO Software
M4 TORNADO
71
Table 22 Steps for the Spectra matching procedure
Object Description
Left side of the dialog Setting of the matching conditions. The search
requires 3 steps.
Defines the sources for the search of matching
spectra. This is possible:
in a selected folder (with subfolders). The
selection can be performed with .
in the project
in the standard library, if available
Sets the sensitivity for searching
Starts the search process. When completed, the
number of searched spectra and identified spectra
is displayed.
After changing the sensitivity the spectrum search
has to be started again.
Right side of the dialog Displays matching results.
The results are presented in the spectrum display.
For a detailed description of the display options,
please refer to section 6.3.2.
The matching results are listed according their
similarity to the unknown spectrum. The highest
probability is on the top. The display functions have
already be described in the mentioned section.
