Using the M4 TORNADO Software
86
User Manual
6.5.1 Definition of measurement conditions
6.5.1.1 Sample positioning
Three camera systems and various modes for stage movement are available to guarantee the
exact positioning of the sample required by the small spot of the excitation radiation. Two camera
images with different options can be displayed simultaneously on the left hand side of the screen
(see Fig. 30).
Table 30 Options for the sample image
Object Description Hints
Arrangement of several images of the 10x
camera that allows the view of large
sample areas
View from the top of the sample with a size
of 14 mm x 11 mm, a cross hair marks the
position of the measurement point
View from the top of the sample with a size
of 1.4 mm x 1.1 mm, a circle marks the
position of the measurement point
Look inside the sample chamber from the
door with a fisf eye camera
Use the corresponding tab to
switch between the different
sample views.
Import/Export menu for images See Fig. 9
Toggle switch for click & drag This function allows easy
sample positioning by clicking
on the position of interest. The
stage moves into that position.
Toggle switch for stage movement with
mouse joystick
This function offers a
continuous movement in
direction of the deviation of
mouse from spot position
Z-movement with mouse in direction of the
mouse cursor in 10x, 100x mag image and
Overview
Image memory Allows saving of images
together with stage position with
“+”
These positions are saved
together with the stage position
and can be called by the
number of the position.
