Buderus Logamatic 4323 Service Instructions

Carrying out a relay test
16
Logamatic 4323 - Subject to technical modifications.
99
Relay test example
Call up the service level. "Gen. parameters" is shown as the first main menu.
Turn the rotary selector until the main menu "Relay test" appears.
The display shows the selected main menu.
Press "Display" to call up a submenu (here: "Heating circ. 0").
The display shows the selected submenu.
Turn the rotary selector until submenu "Heating circ. 2" appears.
The display shows the selected submenu.
Press "Display" to call up a further submenu
(here: "Circ. pump").
The display shows the selected submenu.
+
+
SERVICE LEVEL
Relay test
RELAY TEST
Heating circ. 0
RELAY TEST
Heating circ. 2
RELAY TEST
off
Circ. pump
Heating circ. 2
