Carrying out a relay test
16
Logamatic 4323 - Subject to technical modifications.
100
Turn the rotary selector until submenu "Servomotor" appears.
The display shows the selected submenu.
Hold down "Display" and turn the rotary selector until the required value appears
(here: "closed").
The display shows the set value.
Release "Display" to save your input.
Press "Back" twice to return to the next levels up.
This ends the relay test. This will also be the case when you close the flap.
RELAY TEST
off
Servomotor
Heating circ. 2
+
RELAY TEST 2
closed
Servomotor
Heating circ. 2
USER INFORMATION
All relay test settings are cancelled at the end of the test.
