Appendix B, Wiring B-1
HOME
APPENDIX B - ELECTRICAL CONNECTORS B.1
GENERAL
The following table provides a brief description of the connec-
tors found on the S3T Thunderbolt.
Connector numbers are listed in [brackets] in this manual.
Table B-1. Electrical Connectors
Connector Component(s) Description
[10] Electronic Control Module (Black) 12-place Deutsch
[11] Electronic Control Module (Gray) 12-place Deutsch
[14] Cam Position Sensor 3-place Deutsch
[21] Front Brake Switch 2-place Amp Multilock
[21] Indicator Lamps 12-place Amp Multilock
[22]
Right Handlebar Switch Housing-Ignition
Power, Module and Starter
4-place connector
[24]
Left Handlebar Switch Housing-
Horn, Turn Signals, Lights
9-place connector
[30] Flasher Relay 3-place relay connector
[33] Ignition/Headlamp Switch 4-place Packard
[38] Headlamp 4-place Amp Multilock
[39] Speedometer and Tachometer 10-place connector
[46] Voltage Regulator/Stator 2-place plug
[60] Side Stand Switch 2-place Amp Multilock
[61]
Four 15 Amp Fuses for Clock/Odometer,
Instruments, Lights and Accessories and
One 20 Amp Fuse for Ignition
5-slot fuse block
[65] Speed Sensor 3-place Deutsch
[83] Ignition Coil 3-place Packard
[84] Front Fuel Injector 2-place connector
[85] Rear Fuel Injector 2-place connector
[86] Fuel Pump 4-place connector
[88 Throttle Position Sensor 3-place connector
[89] Intake Air Temperature Sensor 2-place connector
[90] Engine Temperature Sensor 1-place connector
[91A] Data Link 4-place Deutsch
[95] Clutch Switch 2-place Amp Multilock
[96] Clock 4-place plug
[134] Bank Angle Sensor 3-place connector
