2002 Buell S3T: Drive/Transmission 6-1
HOME
SPECIFICATIONS 6.1
*Final gear ratios indicate number of mainshaft revolutions
required to drive output sprocket one revolution.
**Overall gear ratios indicate number of engine revolutions
required to drive rear wheel one revolution.
NOTE
Service wear limits are given as a guideline for measuring
components that are not
new
. For measurement specifica-
tions not given under SERVICE WEAR LIMITS, see NEW
COMPONENTS.
TRANSMISSION
Transmission Type 5 forward speed, foot shift
Clutch Type Wet – multiple disc
Clutch Fluid Capacity 1.0 quart 0.95 liter
Fluid Part No.-Quart 98854-96
Fluid Part No.-Gallon 98855-96
TRANSMISSION GEAR
RATIOS
FINAL* OVERALL**
First (Low) Gear 2.69 9.047
Second Gear 1.85 6.687
Third Gear 1.43 4.823
Fourth Gear 1.18 3.973
Fifth (High) Gear 1.00 3.366
PRIMARY DRIVE (ENGINE-TO-TRANSMISSION)
Engine Sprocket 35 teeth
Clutch Sprocket 56 teeth
Ratio 1.60: 1
FINAL DRIVE (TRANSMISSION-TO-REAR WHEEL)
Transmission Sprocket 27 teeth
Rear Wheel Sprocket 61 teeth
Drive Belt 128 teeth
Ratio 2.10:1
CLUTCH PLATE
THICKNESS
NUMBER
REQUIRED
NEW COMPONENTS SERVICE WEAR LIMITS
IN. MM IN. MM
Friction Plate (Fiber) 8 0.0866 + 0.0031 2.1996 + 0.0787 0.006 0.152
Steel Plate 6 0.0629 + 0.0020 1.5977 + 0.0508 0.006 0.152
Clutch Pack
0.661
minimum
16.789
minimum
5
